6.5Inch High Brightness Screen VGA Lcd Panel NL6448BC20-30C 1000Cd/M2 For Outdoor

Model Number : NL6448BC20-30C

Place of Origin : China

MOQ : 1

Price : negotiable

Payment Terms : T/T

Supply Ability : 5000pcs/month

Delivery Time : 3-5 working days

Packaging Details : factory original packing

Resolution : 640(RGB)×480, VGA 122PPI

Luminance : 1000 cd/m² (Typ.)

Operating Temperature : -30 ~ 80 °C

Storage Temperature : -30 ~ 80 °C

Application : Outdoor high brightness

Contact Now

6.5Inch 640(RGB)×480, VGA Lcd Panel NL6448BC20-30C Luminance 1000 cd/m² for Outdoor application

The NL6448BC20-30C is a 6.5 inch diagonal a-Si TFT-LCD display panel with an integral WLED backlight system, backlight driver optional , without touch screen. It features an operating temperature range of -30 ~ 80°C , a storage temperature range of -30 ~ 80°C , and the maximal vibration level of 2.0G (19.6 m/s²).

Brand: TIANMA
Model P/N: NL6448BC20-30C

Diagonal Size: 6.5"
Panel Type: a-Si TFT-LCD, LCM

Resolution: 640(RGB)×480, VGA 122PPI
Pixel Format: RGB Vertical Stripe

Active Area: 132.48(W)×99.36(H) mm
Bezel Opening: 135.5(W)×102.4(H) mm

Outline Dim.153(H)×118(V)×8.7(D) mm
TreatmentClear, Hard coating (2H), Antireflection

Luminance1000 cd/m² (Typ.)
Contrast Ratio800:1 (Typ.) (TM)

View Direction6 o'clock
Response Time3/15 (Typ.)(Tr/Td)

Viewing Angle80/80/80/80 (Typ.)(CR≥10)
Operating ModeTN, Normally White, Transmissive

Support Color262K/16.7M 40% NTSC
Light SourceWLED [4 strings] , 70K hours , Optional

Weight155/165g (Typ./Max.)
Designed For

Frame Rate60Hz
Touch PanelWithout

Interface Type
LVDS (1 ch, 6/8-bit) , 20 pins Connector

Power Supply
3.3V (Typ.)

Environment
Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C ; Vibration Level: 2.0G (19.6 m/s²)

Product Tags:

6.5Inch high brightness screen

high brightness screen VGA

lcd lvds interface 1000Cd/M2
